| Nominal Capacity | 650mAh |
| Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃ |
| Nominal Voltage | 3.0 V |
| Maximum Continuous Current | 200mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 500mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -40℃ to +70℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 6.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Battery Characteristic
Nominal voltage up to 3.0 V
Energy density up to 450Wh/kg
- Wide Operating Temperature Range
-40°C to +70°C
Self discharge rate is less than 2% per year at room temperature
No passivation effect, instant install-and-use, maintenance free
Battery of variable dimensions can be selected to fit in the customer’s design
Custom batteries and battery packs are also available
The structure of the battery offers greater safety to meet customer’s requirement for special
2. Main Applications
-
Security
Smoke detectors, security alarms, seismometers, digital door lock system, etc.
-
Internet of Things
Asset tracking toll-gate transponders smart home bike-sharing IC cards GPS, TPMS, RFID, etc.
-
Monitoring
Animal health monitoring system,forest fire alert, smart irrigation system, etc.
3. Manufacturing Advantages
-
HCB Battery Co., Ltd. was founded in 2001. As a leading primary lithium battery manufacturer and solution provider in China, HCB remains dedicated to leading the R&D and manufacturing of various types of primary lithium batteries.
4.FAQS of General Safety Instructions
- If the positive and negative polarity of a battery is directly connected, what will happen?
The batteries can’t be short circuit. If positive and negative polarity of a battery is directly connected, this may cause a short circuit and this may lead to toxic materials or gas leakage and/or violent rupture.
- Can the batteries be mixed to use on different electrochemical system, grades or brands?
When changing batteries be aware that batteries of different electrochemical system, grades, or brands should be not mixed. If different batteries are used or in case of using old and new batteries together this can discharge batteries due to different voltage or capacity. This can cause toxic material or gas leakage and/or violent rupture.
- Can the primary batteries be charged?
If you charge the primary batteries, it can lead to toxic material or gas leakage and maybe cause big rupture or fire.
